Canare L-5CFW 300M Flexible Digital Coaxial Cable (984')

SKU

L-5CFW 200M BLK

Request for Price

Key Features

Serial Digital Video Coaxial Cable
75 Ω Nominal Impedance
Low Loss Coax
Foamed PE Insulation
100% Sweep Tested
Ideal for Mobile HD Applications

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

The Canare L-5CFW 300M Flexible Digital Coaxial Cable (984’) is a precision serial digital video coaxial cable that supports a full range of video formats for professional broadcast applications. This cable is ideal for HD-SDI distribution.

Solid copper center conductor

Double braided shield enables flexibility and good bending performance

Foam PE dielectric insulation

Precision, 100% sweep tested coax

Ideal for HD-serial digital video, HDTV upgrade, and broadband applications

Supports SMPTE 259M, 292M, and 424M signals

Double braided shield enables flexibility and good bending performance

Reviews

Write Your Own Review

You're reviewing:Canare L-5CFW 300M Flexible Digital Coaxial Cable (984')

Your Rating

Rating

1 star 2 stars 3 stars 4 stars 5 stars

Nickname

Summary

Review

items Included

Canare L-5CFW 300M Flexible Digital Coaxial Cable (984')

Specification

More Information

SPECS

Dielectric (Insulation)	Material: Foam PE Strength: 1000 VAC / min
Outer Diameter	Nominal: 0.30" (7.7 mm) Inner Conductor: 0.04" (1.05 mm) Insulation: 0.19" (4.9 mm)
Conductor Material	Bare copper #18 (AWG)
Shield Material Coverage	Inner: 0.12TA mm 7 ends 24 carriers (93% or more) Outer: 0.12TA mm 9 ends 24 carriers (96% or more)
Conductor	Composition: 18x AWG 1/0.5A (Quantity / mm)
Attenuation	At 10 MHz: 2.1 dB per 100 m
Conductor D.C.R.	2.3 Ω per 100 m
Shield D.C.R	0.5 Ω per 100 m
Nominal Capacitance	At 1 KHz: 17 pF per ft (55 pF per meter)
Impedance	75 Ω
Length	984' (300 m)
Weight	Approximately 61.00 lb (27.67 kg)
