Digigram 1RU Stereo IP Aud Codec f/STL/SSL-2 I/O Ch's/2 Mono Analog I/Os,1 Stereo AES/EBU I/Os,2 I/O Channel

SKU

VB2342A0101

$2,350.00

Product Highlights

● Two internal redundant power supply units (2x220 VAC, optionally 220VDC / -48VDC)
● 4 Ethernet ports via RJ-45 connectors. 1 x 100 Mbits/s, and 3 x 100/1000 Mbits/s ports
● 2 balanced analog line inputs and outputs
● 1 AES/EBU input and output
● Switchable hardware by-pass on inputs to outputs in case of power supply failure
● 1 RS232 port for auxiliary data tunneling
● 8 GPIO’s, or 4 GPIO’s if the 10 MHz / 1 PPS external synchro input(s) are used (optional)
● External synchronization: AES/EBU input, 10 MHz (Optional), PTP clock, Livewire clock
● Status LEDs
● SDHC card reader
● 6.35mm headphones jack with volume knob and codec input/output selection
