Kiloview P1 P Series 4G Cellular Bonding Video Encoder

SKU
KV-P1
Kiloview
Request for Price

Product Highlights:

  • Dual-Stream Output, Main and Sub
  • 2x Internal, 2x External 4G Antennas
  • Convert SDI to IP
  • Simultaneously Stream to 16 Platforms
  • Wi-Fi and RJ45 Outputs
  • Supports up to 1080p60
  • microSD Card Slot
  • Web-Based Interface
  • Supports RTMP/HLS/SRT/TS Protocols
  • Portable Form Factor

Simultaneously stream your Full HD video to up to 16 x platforms with this HDMI 4G Bonding SDI Video Encoder for Outdoor Live or IRL Streaming from Kiloview. The small, portable unit inputs 3G-SDI video up to 1080p60 and outputs the signal over cellular bonding, for North America only, as well as via Wi-Fi and Ethernet.

It supports RTMP/HLS/SRT/TS streaming media protocols, allowing it to work with a variety of platforms. Powered by an internal battery, the encoder supports embedded audio and 3.5mm analog audio input and output in ACC or G.711 format. It features a microSD card slot for recording your video, and it supports PTZ control over USB.

Up to 5 Connections

2 x Internal 4G Cellular + 2 x USB 4G Cellular (LAN) + 1 x Wi-Fi (+ 1 RJ45) supported and it's free configurable of any desired network

Cellular Bonding

With the patented bonding algorithm with KiloLink, P series encoders can automatically balance the data of all connections and adjust the bitrate accordingly to make sure the reliable streaming. In addition, the P1 can support Wi-Fi hotspot for data and file transmission.

Self-Deploy Bonding Cloud With Device Management

  • Kiloview provides the bonding software for free; it's available for deployment on your own server or cloud-based server.
  • With KiloLink Server, you can manage all your registered devices on the server end, such as monitoring device status, preview a stream, parameter settings, firmware updating, port forwarding and so on. Real time connection status and data statistics are also available on server end.
  • It's easy to manage with a single QR code.

Ultra-Low Latency for End-to-End Video Transmission

With optimized technology, Kiloview P series offers a ultra-low latency video streaming experience, which is suitable for remote production, IRL streaming, or audience interaction with high quality. End to end latency with 4G-bonding server is less than one-second under normal working conditions.

RSTP, RTMP, SRT, HLS, and TS-UDP

No matter if you are using a single connection or the bonding connection, with Kiloview P series, you can not only stream your video to YouTube/Facebook and other platforms with RTMP(S), but also transmit your video remotely by SRT and other workflows using different protocols such as RTSP, UDP, and HLS. Outdoor streaming was never so easy.

Multiple Platform Streaming

Kiloview P series encoder supports streaming to 16 platforms simultaneously by configuring the main and sub-stream in the web console, that means you can stream to all the popular platforms with the same content. (Main stream resolution up to 1080P60, sub-stream resolution up to 720P60).

Video Rotate/Crop, and Image Overlay

With FPGA processing unit, it can easily realize the functions of rotating and cropping for vertical/horizontal video, which makes it social media friendly. You can also mirror the stream, or adjust the color. Moreover, you can set your overlay image at any position such as adding a logo, text, etc.
Write Your Own Review
You're reviewing:Kiloview P1 P Series 4G Cellular Bonding Video Encoder
Your Rating

Items included :

P series encoder PCS 1
4G Antenna PCS 2
DC12V/1A power adaptor PCS 1
USB-DC cable PCS 1
USB-RJ45 converter PCS 1
Hot shoe rack PCS 1
Hot shoe bracket PCS 1
Quick start guide PCS 1
Certificate/Warranty card PCS 1
More Information
SPECS
Model No. P1, P2
Input SDI (P1): HDMI (P2)
Transmission mode 4G-LTE, WIFI (2.4/5G dual band), Ethernet by USB expansion
4G bonding capacity 4 channels of 4G bonding (2 CH internal+ 2 CH external)
Video resolution Up to 1080P60Hz:
1080p23.98/24/25/29.97/30
1080p50/59.94/60
1080i50/59.94/60
720p23.98/24/25/29.97/30
720p50/59.94/60
Video encoding H.264/AVC, Motion-JPEG
Audio encoding AAC/G.711
Encoding latency <67ms
Media protocol RTMP/RTSP/SRT/RTP/HLS/TS over UDP, custom for SIP
Graphic overlay User-defined text, image overlay
Recording TF card slot/hard disk by USB expansion for local recording and NAS network storage
Management Android APP/Web
Hot shoe Removable
Battery capacity 3.7V 6800mAh (29.6Wh)
Power supply DC 12V 1A
Power consumption 6.5w
Operating temperature -20~45℃
Dimension 115*75*35mm (4.53”*2.95”*1.38”)
Weight 400g (14 oz)
