AJ-PX270 - Specification
General Specification |
Pickup Devices: | 1/3-type 2.2 million pixels, MOS solid state image sensor x 3 |
Lens: | Optical image stabilizer lens, optical 22x motorized zoom F1.6 to F3.2 (f=3.9 mm to 86 mm) 35 mm conversion: 28 mm to 616 mm (16:9) |
Filter Diameter: | 72 mm |
Optical System: | Prism system |
ND Filter: | OFF, 1/4, 1/16, 1/64 |
Shortest Shooting Distance (M.O.D.): | 1.1 m from the front lens Approx. 0.06 m from front lens (When Macro=On, at wide-end) |
Gain Settings: | L/M/H selector switch-3 dB to 18 dB (in 1 dB steps) (Negative value of gain is only in [HIGH SENS.] mode.) (When assigning [S.GAIN] to the USER button: Switching between 24 dB, 30 dB, and 36 dB) |
Color Temperature Setting: | ATW, ATW LOCK, Ach, Bch, preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K) |
Shutter Speed: | When [SYSTEM MODE] = 59.94 Hz 60i/60p mode: 1/60 (shutter off) sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 30p mode: 1/30 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 24p mode: 1/24 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. When [SYSTEM MODE] = 50 Hz 50i/50p mode: 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 25p mode: 1/25 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. |
Slow Shutter Speed: | Setting is possible when [VFR]=[OFF] When [SYSTEM MODE] = 59.94 Hz 60i/60p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec., 1/30 sec. 30p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6sec., 1/15 sec. 24p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec. When [SYSTEM MODE] = 50 Hz 50i/50p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec., 1/25 sec. 25p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec. |
Synchro Scan Shutter: | When [SYSTEM MODE] = 59.94 Hz and [SYNC SCAN TYPE] = [sec] 60i/60p mode: 1/60.0 sec. to 1/249.8 sec. 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec. When [SYSTEM MODE] = 50 Hz and [SYNC SCAN TYPE] = [sec] 50i/50p mode: 1/50.0 sec. to 1/250.0 sec. 25p mode: 1/25.0 sec. to 1/250.0 sec. |
Shutter Open Angle: | 3.0 deg to 180.0 deg to 360.0 deg (in 0.5 deg steps, angle display) |
VFR Recording Frame Rate: | 1080/59.94p: 1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 24, 25, 26, 27, 28, 30, 32, 34, 36, 40, 44, 48, 54, and 60 (frames per second) 1080/50p: 1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 32, 34, 37, 42, 45, 48, and 50 (frames per second) |
Sensitivity: | [HIGH SENS.] mode F11 (2000 lx, 3200 K, 89.9 % reflection, 1080/59.94i) F12 (2000 lx, 3200 K, 89.9 % reflection, 1080/50i) |
Minimum Subject Illumination: | 0.02 lx (F1.6, gain 18 dB, [1S.EXP.], [HIGH SENS.] mode) |
Digital Zoom: | x2/x5/x10 |
Lens Hood: | Hood with lens cover |
Pickup Devices: | 1/3-type 2.2 million pixels, MOS solid state image sensor x 3 |
Lens: | Optical image stabilizer lens, optical 22x motorized zoom F1.6 to F3.2 (f=3.9 mm to 86 mm) 35 mm conversion: 28 mm to 616 mm (16:9) |
Filter Diameter: | 72 mm |
Optical System: | Prism system |
ND Filter: | OFF, 1/4, 1/16, 1/64 |
Shortest Shooting Distance (M.O.D.): | 1.1 m from the front lens Approx. 0.06 m from front lens (When Macro=On, at wide-end) |
Gain Settings: | L/M/H selector switch-3 dB to 18 dB (in 1 dB steps) (Negative value of gain is only in [HIGH SENS.] mode.) (When assigning [S.GAIN] to the USER button: Switching between 24 dB, 30 dB, and 36 dB) |
Color Temperature Setting: | ATW, ATW LOCK, Ach, Bch, preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K) |
Shutter Speed: | When [SYSTEM MODE] = 59.94 Hz 60i/60p mode: 1/60 (shutter off) sec., 1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 30p mode: 1/30 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 24p mode: 1/24 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. When [SYSTEM MODE] = 50 Hz 50i/50p mode: 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. 25p mode: 1/25 sec., 1/50 (shutter off) sec., 1/60 sec., 1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec. |
Slow Shutter Speed: | Setting is possible when [VFR]=[OFF] When [SYSTEM MODE] = 59.94 Hz 60i/60p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec., 1/30 sec. 30p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6sec., 1/15 sec. 24p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec. When [SYSTEM MODE] = 50 Hz 50i/50p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec., 1/25 sec. 25p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec. |
Synchro Scan Shutter: | When [SYSTEM MODE] = 59.94 Hz and [SYNC SCAN TYPE] = [sec] 60i/60p mode: 1/60.0 sec. to 1/249.8 sec. 30p mode: 1/30.0 sec. to 1/249.8 sec. 24p mode: 1/24.0 sec. to 1/249.8 sec. When [SYSTEM MODE] = 50 Hz and [SYNC SCAN TYPE] = [sec] 50i/50p mode: 1/50.0 sec. to 1/250.0 sec. 25p mode: 1/25.0 sec. to 1/250.0 sec. |
Shutter Open Angle: | 3.0 deg to 180.0 deg to 360.0 deg (in 0.5 deg steps, angle display) |
VFR Recording Frame Rate: | 1080/59.94p: 1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 24, 25, 26, 27, 28, 30, 32, 34, 36, 40, 44, 48, 54, and 60 (frames per second) 1080/50p: 1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30, 32, 34, 37, 42, 45, 48, and 50 (frames per second) |
Sensitivity: | [HIGH SENS.] mode F11 (2000 lx, 3200 K, 89.9 % reflection, 1080/59.94i) F12 (2000 lx, 3200 K, 89.9 % reflection, 1080/50i) |
Minimum Subject Illumination: | 0.02 lx (F1.6, gain 18 dB, [1S.EXP.], [HIGH SENS.] mode) |
Digital Zoom: | x2/x5/x10 |
Lens Hood: | Hood with lens cover |
Memory Card Recorder Section |
Recording Slot: | microP2 card slot x2, P2 card slot x1 |
System Format: | 1080/59.94p, 1080/59.94i, 1080/23.98PsF, 720/59.94p, 480/59.94i, 1080/50p, 1080/50i, 720/50p, 576/50i |
Recording Formats: | AVC-Intra200/AVC-Intra100/AVC-Intra50/ AVC-LongG50/AVC-LongG25/AVC-LongG12 DVCPRO HD/DVCPRO50/DVCPRO/DV formats |
Recording Video Signal: | 1080/59.94p, 1080/59.94i, 1080/29.97pN, 1080/23.98pN, 720/59.94p, 720/29.97pN, 720/23.98pN, 480/59.94i, 480/29.97p 1080/50p, 1080/50i, 1080/25pN, 720/50p, 720/25pN, 576/50i, 576/25p |
Recording/Playback Time*1: | 16 GBx1 32 GBx1 64 GBx1 AVC-Intra200: Approx. 8 min. Approx. 16 min. Approx. 32 min. AVC-Intra100: Approx. 16 min. Approx. 32 min. Approx. 64 min. AVC-Intra50: Approx. 32 min. Approx. 64 min. Approx. 128 min. AVC-LongG50: Approx. 32 min. Approx. 64 min. Approx. 128 min. AVC-LongG25: Approx. 64 min. Approx. 128 min. Approx. 256 min. AVC-LongG12: Approx. 120 min. Approx. 240 min. Approx. 480 min. DVCPRO HD: Approx. 16 min. Approx. 32 min. Approx. 64 min. DVCPRO 50: Approx. 32 min. Approx. 64 min. Approx. 128 min. DVCPRO/DV: Approx. 64 min. Approx. 128 min. Approx. 256 min. |
Recording Slot: | microP2 card slot x2, P2 card slot x1 |
System Format: | 1080/59.94p, 1080/59.94i, 1080/23.98PsF, 720/59.94p, 480/59.94i, 1080/50p, 1080/50i, 720/50p, 576/50i |
Recording Formats: | AVC-Intra200/AVC-Intra100/AVC-Intra50/ AVC-LongG50/AVC-LongG25/AVC-LongG12 DVCPRO HD/DVCPRO50/DVCPRO/DV formats |
Recording Video Signal: | 1080/59.94p, 1080/59.94i, 1080/29.97pN, 1080/23.98pN, 720/59.94p, 720/29.97pN, 720/23.98pN, 480/59.94i, 480/29.97p 1080/50p, 1080/50i, 1080/25pN, 720/50p, 720/25pN, 576/50i, 576/25p |
Recording/Playback Time*1: | 16 GBx1 32 GBx1 64 GBx1 AVC-Intra200: Approx. 8 min. Approx. 16 min. Approx. 32 min. AVC-Intra100: Approx. 16 min. Approx. 32 min. Approx. 64 min. AVC-Intra50: Approx. 32 min. Approx. 64 min. Approx. 128 min. AVC-LongG50: Approx. 32 min. Approx. 64 min. Approx. 128 min. AVC-LongG25: Approx. 64 min. Approx. 128 min. Approx. 256 min. AVC-LongG12: Approx. 120 min. Approx. 240 min. Approx. 480 min. DVCPRO HD: Approx. 16 min. Approx. 32 min. Approx. 64 min. DVCPRO 50: Approx. 32 min. Approx. 64 min. Approx. 128 min. DVCPRO/DV: Approx. 64 min. Approx. 128 min. Approx. 256 min. |
|
: | |
: | |
: | |
: | |
Digital Video |
Sampling Frequency: | AVC-Intra200/AVC-Intra100/AVC-Intra50/AVC-LongG50/ AVC-LongG25/AVC-LongG12/DVCPRO HD Y: 74.1758 MHz, PB/PR: 37.0879 MHz (59.94 Hz) Y: 74.2500 MHz, PB/PR: 37.1250 MHz (50 Hz) DVCPRO50 Y: 13.5 MHz, PB/PR: 6.75 MHz DVCPRO Y: 13.5 MHz, PB/PR: 3.375 MHz |
Quantizing: | AVC-Intra200/AVC-Intra100/AVC-Intra50/AVC-LongG50/ AVC-LongG25: 10 bits AVC-LongG12/DVCPRO HD/DVCPRO50/DVCPRO/DV: 8 bits |
Video Compression Format: | AVC-Intra200/AVC-Intra100/AVC-Intra50: MPEG-4 AVC/H.264 Intra Profile AVC-LongG50/AVC-LongG25/AVC-LongG12: MPEG-4 AVC/H.264 DVCPRO HD: DV-Based Compression (SMPTE 370M) DVCPRO50/DVCPRO: DV-Based Compression (SMPTE 314M) DV: DV Compression (IEC 61834-2) |
Sampling Frequency: | AVC-Intra200/AVC-Intra100/AVC-Intra50/AVC-LongG50/ AVC-LongG25/AVC-LongG12/DVCPRO HD Y: 74.1758 MHz, PB/PR: 37.0879 MHz (59.94 Hz) Y: 74.2500 MHz, PB/PR: 37.1250 MHz (50 Hz) DVCPRO50 Y: 13.5 MHz, PB/PR: 6.75 MHz DVCPRO Y: 13.5 MHz, PB/PR: 3.375 MHz |
Quantizing: | AVC-Intra200/AVC-Intra100/AVC-Intra50/AVC-LongG50/ AVC-LongG25: 10 bits AVC-LongG12/DVCPRO HD/DVCPRO50/DVCPRO/DV: 8 bits |
Video Compression Format: | AVC-Intra200/AVC-Intra100/AVC-Intra50: MPEG-4 AVC/H.264 Intra Profile AVC-LongG50/AVC-LongG25/AVC-LongG12: MPEG-4 AVC/H.264 DVCPRO HD: DV-Based Compression (SMPTE 370M) DVCPRO50/DVCPRO: DV-Based Compression (SMPTE 314M) DV: DV Compression (IEC 61834-2) |
Digital Audio Specification |
Recording Audio Signal: | AVC-Intra200/AVC-LongG50/AVC-LongG25: 48 kHz/24 bits, 4 CH AVC-Intra100/AVC-Intra50: 48 kHz/16 bits, 4 CH and 48 kHz/24 bits, 4 CH switch AVC-LongG12/DVCPRO HD/DVCPRO50: 48 kHz/16 bits, 4 CH DVCPRO/DV: 48 kHz/16 bits, 4 CH |
Headroom: | 12 dB/18 dB/20 dB switchable menu |
Recording Audio Signal: | AVC-Intra200/AVC-LongG50/AVC-LongG25: 48 kHz/24 bits, 4 CH AVC-Intra100/AVC-Intra50: 48 kHz/16 bits, 4 CH and 48 kHz/24 bits, 4 CH switch AVC-LongG12/DVCPRO HD/DVCPRO50: 48 kHz/16 bits, 4 CH DVCPRO/DV: 48 kHz/16 bits, 4 CH |
Headroom: | 12 dB/18 dB/20 dB switchable menu |
AVC Proxy |
File Format: | MOV |
Video Compression Format (AVC Proxy): | H.264/AVC Baseline Profile, H.264/AVC High Profile |
File Format: | MOV |
Video Compression Format (AVC Proxy): | H.264/AVC Baseline Profile, H.264/AVC High Profile |
General Specifications |
Audio Compression Format: | AAC-LC, Linear PCM |
Approximate Recording Time (1GB)*2: | AVC-G6 2CH MOV: Approx. 13 min. SHQ 2CH MOV: Approx. 25 min. HQ 2CH MOV: Approx. 78 min. LOW 2CH MOV: Approx. 135 min. |
Audio Compression Format: | AAC-LC, Linear PCM |
Approximate Recording Time (1GB)*2: | AVC-G6 2CH MOV: Approx. 13 min. SHQ 2CH MOV: Approx. 25 min. HQ 2CH MOV: Approx. 78 min. LOW 2CH MOV: Approx. 135 min. |
Video Input/Output |
SDI Out: | BNC x 1, HD (3G/1.5G), SD: 0.8 V [p-p], 75 ohms |
Video Output: | BNC x 1, Also used as the GENLOCK IN, IN/OUT switch selection Composite: 1.0 V [p-p], 75 ohms |
HDMI Out: | HDMI x 1 (HDMI type A terminal, not compatible with VIERA Link) |
SDI Out: | BNC x 1, HD (3G/1.5G), SD: 0.8 V [p-p], 75 ohms |
Video Output: | BNC x 1, Also used as the GENLOCK IN, IN/OUT switch selection Composite: 1.0 V [p-p], 75 ohms |
HDMI Out: | HDMI x 1 (HDMI type A terminal, not compatible with VIERA Link) |
Audio Input |
Built-in Microphone: | Supports stereo microphone |
Audio Input 1/Audio Input 2: | XLR x 2, 3 pin.Input high impedance, LINE/MIC switch selection LINE: 4 dBu/0 dBu (selectable menu) MIC: -40 dBu/-50 dBu/-60 dBu (selectable menu), +48 V on/off (switch selection) |
Built-in Microphone: | Supports stereo microphone |
Audio Input 1/Audio Input 2: | XLR x 2, 3 pin.Input high impedance, LINE/MIC switch selection LINE: 4 dBu/0 dBu (selectable menu) MIC: -40 dBu/-50 dBu/-60 dBu (selectable menu), +48 V on/off (switch selection) |
Audio Output |
Audio Out: | 3.5 mm diameter stereo mini jack x 1, Output level: 600 ohms, 316 mV |
Headphone: | 3.5 mm diameter stereo mini jack x 1 100 ohms, -16 dBV (32 ohms load, at maximum output level) |
Speaker: | 20 mm diameter, round x 1 |
Audio Out: | 3.5 mm diameter stereo mini jack x 1, Output level: 600 ohms, 316 mV |
Headphone: | 3.5 mm diameter stereo mini jack x 1 100 ohms, -16 dBV (32 ohms load, at maximum output level) |
Speaker: | 20 mm diameter, round x 1 |
Other Input/Output |
Cam Remote: | 2.5 mm diameter super mini jack x1 ZOOM S/S |
Genlock In: | BNCx1, also used as the VIDEO OUT, IN/OUT switch selection, 1.0 V [p-p], 75 ohms |
TC In/Out: | BNCx1 Used as the input and output terminals, IN/OUT switch selection Input: 1.0 V - 4.0 V [p-p], 10 k ohms Output: 2.0 V±0.5 V [p-p], low impedance |
LAN: | 100BASE-TX/10BASE-T |
USB 2.0 (Device): | Type miniB connector, 4 pin |
USB 3.0 (Host): | Type A connector, 9 pin |
USB 2.0 Host (Sub-Host): | Type A connector, 4 pin (exclusively for wireless module AJ-WM30) |
DC In 12V: | DC 12 V (DC 10.5 V - 13.5 V), EIAJ type 4 |
Cam Remote: | 2.5 mm diameter super mini jack x1 ZOOM S/S |
Genlock In: | BNCx1, also used as the VIDEO OUT, IN/OUT switch selection, 1.0 V [p-p], 75 ohms |
TC In/Out: | BNCx1 Used as the input and output terminals, IN/OUT switch selection Input: 1.0 V - 4.0 V [p-p], 10 k ohms Output: 2.0 V±0.5 V [p-p], low impedance |
LAN: | 100BASE-TX/10BASE-T |
USB 2.0 (Device): | Type miniB connector, 4 pin |
USB 3.0 (Host): | Type A connector, 9 pin |
USB 2.0 Host (Sub-Host): | Type A connector, 4 pin (exclusively for wireless module AJ-WM30) |
DC In 12V: | DC 12 V (DC 10.5 V - 13.5 V), EIAJ type 4 |
Monitor |
LCD Monitor: | 3.5 type QHD color monitor (Approx. 1560000 dots) |
View Finder: | 0.5 type OLED (organic EL display) (Approx. 2360000 dots, video display area: Approx. 1770000 dots) |
LCD Monitor: | 3.5 type QHD color monitor (Approx. 1560000 dots) |
View Finder: | 0.5 type OLED (organic EL display) (Approx. 2360000 dots, video display area: Approx. 1770000 dots) |
Accessories |
Included Accessories: | Battery (VW-VBD58), Shoulder strap, Battery charger, AC adaptor, Microphone holder, Screw for microphone holder (12 mm), Power code x 2, Eye cup, Lens hood, Grip belt |
Included Accessories: | Battery (VW-VBD58), Shoulder strap, Battery charger, AC adaptor, Microphone holder, Screw for microphone holder (12 mm), Power code x 2, Eye cup, Lens hood, Grip belt |
Imaging |
Image Sensor: | 3-Chip 1/3" MOS Sensor |
Sensor Resolution: | 1920 x 1080 (2.2 MP) |
Minimum Illumination: | 0.02 Lux at 1/1 Shutter Speed |
Lens |
Optical Zoom Ratio: | 22x |
Camera |
Built-In ND Filter: | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters |
Media/Memory Card Slot: | Dual Slot: microP2
Single Slot: P2
Single Slot: SD/SDHC/SDXC |
Recording |
Recording Modes: | AVC-Intra:
1920 x 1080p at 23.98/25/29.97/50/59.94 fps (50 to 100 Mb/s)
AVC-LongG:
1920 x 1080p at 23.98/25/29.97/50/59.94 fps (12 to 50 Mb/s) |
IP Streaming: | None |
Interfaces |
Video Connectors: | 1 x BNC (3G-SDI) Output
1 x BNC (Composite) Output |
Audio Connectors: | 2 x 3-Pin XLR Input
1 x 1/8" / 3.5 mm Stereo Headphone Output |
Other I/O: | 1 x BNC Timecode Input
1 x BNC Genlock Input
1 x 2.5 mm Camera Interface Control Input
1 x 3.5 mm Camera Interface Control Input |
Display |
Display Type: | Articulating LCD |
Size: | 3.5" |
Resolution: | 1,560,000 Dot |
EVF |
EVF Display Type: | OLED |
Screen Size: | .5" |
EVF Resolution: | 1,760,000 Dots |
Power |
Battery Type: | Panasonic CGA-D54 |
General |
Accessory Mount: | None |
Dimensions: | 6.9 x 6.7 x 13" / 176 x 171 x 329 m |
Weight: | 5.7 lb / 2.6 |
Warranty Length: | None |
Packaging Info |
Package Weight: | 11.65 lb |
Box Dimensions (LxWxH): | 19.1 x 14.8 x 12.8" |
|
