Panasonic TY-FB30DHD3D Dual HD-SDI Terminal Board For 3D

SKU
TYFB30DHD3D
image-icon
$3,000.00
Add to Wish List Add to Compare
Email
main product photo

The Panasonic TY-FB30DHD3D Dual HD-SDI Terminal Board For 3D is an HD-SDI simultaneous input system that allows 3D images to be transmitted in broadcasting and image production workflows. Left-eye and right-eye images are sent through a single coaxial cable.

Write Your Own Review
You're reviewing:Panasonic TY-FB30DHD3D Dual HD-SDI Terminal Board For 3D
Your Rating

Items Included:

  • Panasonic TY-FB30DHD3D Dual HD-SDI Terminal Board For 3D
  • Screws x 4
  • Terminal function label (1 sheet)
  • Operating Instructions
  • 1 Year Warranty

TYFB30DHD3D - Specification

More Information
General
Input Terminal:HD-SDI IN (A): 1x BNC (HD-SDI/ Dual Link HD-SDI A/ 3D SDI left channel)
HD-SDI IN (B): 1x BNC (Dual Link HD-SDI B/ 3D SDI right channel)
Standard:HD-SDI: SMPTE292M
Dual Link HD-SDI: SMPTE372M
Audio:SMPTE299M
Signals Supported:Compatible 3D Signal: Simultaneous/ Side by Side/ Top and Bottom
Dimensions (W x H x D):4.1 x 1.5 x 5.9" (104.5 x 38.5 x 148.9 mm)
Maximum Length:328.08 ft (100 m) (when using a cable with a length of less than 328.08' (100 m), and an attenuation of 20 dB at 750 MHz)
Weight:Approximately 0.55 lb (0.25 kg)
Gross Weight: 1.43 lb (0.65 kg)
Packaging Info
Package Weight:1.2 lb
Box Dimensions (LxWxH):9.2 x 7.7 x 2.4"
