Panasonic TY-TBN03G 3G-SDI Board for 4K Professional Panel Displays

SKU
TY-TBN03G
image-icon
$1,160.50
Add to Wish List Add to Compare
Email

Product Highlights:

  • Compatible with SD, HD, 2K, and 4K video signals
  • Provides simultaneous video and audio signal transmission (up to 16 channels) using a single cable
  • Supports 4K transmission mode of both Square division and 2 sample interleave division
  • Applicable for SLOT NX compatible model (LQ70 series and up)
main product photo

The TY-TBN03G 3G-SDI Board from Panasonic is designed to provide simultaneous video and audio signal transmission to 4K professional panel displays via a single BNC cable. It is applicable for SLOT NX compatible models and is compatible with SD, HD, 2K, and 4K video signals.

  • Compatible with SD, HD, 2K, and 4K video signals
  • Provides simultaneous video and audio signal transmission (up to 16 channels) using a single cable
  • Supports 4K transmission mode of both Square division and 2 sample interleave division
  • Applicable for SLOT NX compatible model (LQ70 series and up)

Note:
Cannot be mounted to displays compatible with SLOT 2.
Write Your Own Review
You're reviewing:Panasonic TY-TBN03G 3G-SDI Board for 4K Professional Panel Displays
Your Rating

Items Included:

  • Panasonic TY-TBN03G 3G-SDI Board for 4K Professional Panel Displays
  • Terminal Function Label
  • 4 x Screws

TY-TBN03G - Specification

More Information
General
Slots:SLOT NX Model: Slot 1, Slot 2
Connectors:3G-SDI Input: 2 x BNC, 0.8 V p-p (75 ohms)
3G-SDI Output: 2 x BNC, active through
Standard Compliance:Video: (3G) SMPTE 424M/425M-1, (DL) SMPTE 372M, (HD) SMPTE 274M/296M, (SD) SMPTE 259M/ITU-R BT 656-4
Audio: (3G,HD) SMPTE 299M, (SD) SMPTE 272M
Video Formats:4K: 4096/60p, 50p, 3840/60p, 50p, 4096/30p, 25p, 24p, 3840/30p, 25p, 24p
2K: 2048/30p, 25p, 24p
HD: 1080/60p, 50p, 30p, 25p, 24p, 1080/60i, 50i, 720/60p, 50p
SD: 525/59.94i, 625/50i
Audio Formats:3G-SDI: 48 kHz, 20/24 bit, 16 channels, synchronized video
HD-SDI: 48 kHz, 20/24 bit, 8 channels, synchronized video
SD-SDI: 48 kHz, 20/24 bit, 4 channels, synchronized video
Dimensions:6.0 x 5.6 x 1.6" (151 x 142 x 38.5 mm)
Weight:Approx. 0.7 lb (340 g)
