SWIT S-2041 Chip Array LED On-camera Light

Request for Price
SKU
S-2041

PRODUCT HIGHLIGHTS

  • Chip Array LED technology
  • 23W, 1200Lux @ 1 meter, dimmerable
  • 100W equivalent output
  • Single shadow, glareless
  • 60° wide beam angle, equally spread
  • Cool touch
  • 5000K color temperature
  • 5600K and 3200K filter
  • Color rendering index: 85
  • 6-17V wide input voltage
  • Interchangeable DV mount and battery
  • Screw and cold shoe mount

The S-2041 on-camera LED light adopts the new generation LED technology called Chip Array LED, which integrates the LEDs into a chip with high brightness output but in smaller size, and the most remarkable, it offers a equally spread, soft, glareless light, similar to the traditional Halogen bulb light.

S-2041 feeds 23W light output, and equivalent to an 100W halogen bulb. The illuminance is 1200 Lux at 1 meter distance and 1 meter sca

The traditional LED lights use lens to converge and get a higher brightness, but dropped down quickly around, which will generate a visible lighting border in the image.
In comparison, the Chip Array LED generates a wider beam angle, equally spread from the center to edge, and suitable for HD shooting.

The traditional LED array always generates several highlight pots on retina and people will feel glaring, even can’t recover sight until a few seconds. In comparison, the SWIT Chip Array LED has only one bulb
in appearance, and output a glareless, single shadow light, suitable
for close interview shooting.

The S-2041 LED has 5000K color temperature and also equipped with a 5600K (Daylight) and a 3200K (Tungsten) color temperature filter. You can switch the color temperature easily.

The S-2041 accepts 6-17V wide voltage input, so you can get power from 14.4V V-mount/Gold Mount batteries or 7.2V DV batteries.
The light package goes with a D-tap to pole-tap cable (S-7104), to plug into the DC-IN port of S-2041 and get power from D-tap power output sockets, such as batteries, battery plates, or camera handle.
You can also directly mount a 7.2V DV battery onto the rear of S-2041, by the particular battery plate.

If you want a compact battery power solution, you may choose SWIT S-8040 Li-ion battery to instead of the DV plates and DV batteries.
The S-8040 is specially used for S-2041, with 7.2V, 21Wh/3Ah capacity, and can run nearly 1 hour on S-2041.

The S-8040 has a 4-level power indicators and a pole-tap charging input socket. You can use SWIT portable Pole-tap charger S-3010D to
charger S-8040.

S-2041 has a dimmer controller to adjust the light output from 10%-100%. The color temperature will not change during the dimmer controlling.

S-2041 can be fixed on camera via 1/4” screw head, and the package also goes with a spare cold shoe part for users to change the screw connector to cold shoe.

  • S-2041 chip array LED On-camera light
  • 1x D-tap to Pole-tap power cable (S-7104)
  • 1x Interchangeable DV plate (S-7004 series, optional for different types)
  • 1x Spare cold-shoe connector
  • 1x Portable bag
  • The S-8040 Li-ion battery and S-3010D charger are optional purchase.
