Sachtler 5201 Vario Pedestal 2-75 (Quick Fix)

SKU
5201
$27,868.25

Product Highlights :

  • Pedestal and Pad Dolly
  • 165 lbs Capacity
  • Crab and Steer
  • Rubber Coated Surfaces
  • Vario Transport Dolly

The Sachtler 5201 2-75 Vario Pedestal is suited for modern broadcast cameras and offers OB and studio packages. The compact, modular construction of these pedestals achieves maximum stability at a relatively low weight. This pedestal is very user friendly offering a Vario dolly and a Quickfix fitting for fast and easy setups without screws.

Modular Design

The modular design of the pedestals means that the steering wheel, column and dolly form three easily portable lightweight components which can be assembled in seconds without tools.

Steering

The crab-and-steer function enables simple maneuvering with defined rolling turns. A small steering wheel is available and can even be used with a teleprompter.

Quickfix

A column lock and Sachtler Quickfix mount are offered for fast changes of the fluid head.

Air Charging

This pedestal offers safe air charging with pressure relief valves. The air charging feature saves on fluid pneumatic costs and can be done with a hand pump or compressor.

Vario Dolly

The Vario dolly works well for applications concerning narrow passage and portability.
Write Your Own Review
You're reviewing:Sachtler 5201 Vario Pedestal 2-75 (Quick Fix)
Your Rating

Items Included :

  • Sachtler 5201 Vario Pedestal 2-75 (Quick Fix)
  • Post
  • Wheel
  • Vario Dolly
  • Pump
  • 6 x Trim Weights
  • Limited 1-Year Warranty, Extendable to 2-Year with Product Registration
More Information
SPECS

Sachtler Vario Ped 2-75 Specs

General
Load Capacity 165 lbs
75kg
Trim Ring Six Trim Weights Included
Bowl Diameter/Thread Flat Base
Quickfix
Steering Ring Diameter Not Specified by Manufactuer
Folded/Transport Length 26"
66cm
Minimum Height 26"
66cm
Maximum Height 56.3"
143cm
Weight 181 lbs
82kg
Post
Stages 2
On-Shot Stroke Not Specified by Manufactuer
Dolly
Doorway Tracking Width 35"
88.8cm
Transit Doorway Width 36.2"
92cm
Narrow Doorway Width 27.2"
69cm
Wheel Diameter 4.9"
125mm
Wheel Lock Yes
Cable Guards Yes
Packaging Info
Package Weight 164 lb
Box Dimensions (LxWxH) 39.5 x 32.5 x 30.5
