Product Highlights :
- 17.6 lb Capacity Fluid Drag Head
- 4.1" Sliding Plate Range
- 8-Step Counterbalance
- 3-Step + 0 Pan/Tilt Drag
- 75mm Bowl Diameter
- 2-Stage/3-Section Leg Design
- Mid-Level Spreader
- 31-67" Height Range
- +90/-75° Tilt Range
The Sachtler Ace XL Tripod System with 75mm bowl combines the Ace XL fluid head with the Ace 75/2 CF carbon fiber tripod and a mid-level spreader. Designed for digital cine-style cameras, the Ace XL supports rigs weighing up to 17.6 pounds. This system is suitable for larger DSLR and mirrorless MFT cameras, as well as pro-style cameras such as the Blackmagic URSA Mini, Canon C200/C300 Mk II, Sony FS7, and the Panasonic EVA1.
The Ace XL fluid head features eight steps of counterbalance and three steps of pan and tilt drag adjustment, plus a zero drag option for pan and tilt. Cameras are mounted using the slide-in balancing plate. With a sliding range of 4.1", this head can adapt to a variety of rig configurations. Additional features include a detachable right-side pan bar and an illuminated bubble level. With an integrated flat head base, the Ace XL can be used when shooting with a slider.
This 75mm bowl-based combo has a 31 to 67" height range for capturing low and high shots. Its integrated mid-level spreader aids in quickly setting the tripod up on level or uneven surfaces. The rubber feet at the base of the two-stage legs can be removed, exposing dual spikes for extra stability outdoors. When you've completed shooting, collapse the Ace XL Tripod System to its 34" folded length and pack it into the included padded case.
Compatible Cameras
Blackmagic URSA Mini/Mini Pro
Canon C200/C300 Mk II
Sony FS series
Panasonic EVA1
Ace XL Fluid Head Features
Ace 75/2 CF Tripod Features
Items Included :
- Sachtler Ace XL Tripod System with CF Legs & Mid-Level Spreader (75mm Bowl)
- Ace 75/2 Carbon Fiber Legs
- Mid-Level Spreader
- 3 x Rubber Feet
- Sachtler Sideload Plate S/Ace Tripod QR Plate
- Sachtler Pan Bar for Ace Tripods
- Padded Bag
- Limited 1-Year Warranty, Extendable to 2-Years with Product Registration
