SWIT S-1053F 5.5" Full HD Waveform LCD Monitor with S-7003C Canon BP Battery Plate
SKU
S-1053FC
$840.00
Product Highlights:
- 5.5" LCD, 1920 x 1080 full HD
- Optical bonding LCD panel
- Metal housing, thinner, and robust
- Peaking focus assist (dual color)
- Timecode, H/V delay, AFD, and scale markers
The S-1053F from SWIT adopts a 5.5” LCD panel with LED backlight and 1920 x 1080 native resolution, a contrast of 1000:1, and viewing angle of 160°/160°. It has an aluminum alloy housing, thinner, and robust, suitable for outdoor on-camera video monitoring. The monitor supports built-in HDMI to SDI conversion and also features a SDI loop output port. It supports 6.5 to 24 VDC input via a 5.5mm lockable DC socket, and comes with a S-7003C Canon BP Battery Plate to be powered by DV batteries.
Furthermore, the monitor supports video analysis assistant patterns and embedded audio monitoring with up to 16 channels SDI and 8 channels HDMI embedded audio meters display, with marks and audio abnormal alert info. It has a revolve/push menu button, with one-button operation for menu system and provides a micro-USB port for firmware upgrade. The monitor includes a foldable sunhood, an AC-DC lockable power adapter, and carrying case.
Monitor
Input/Ouput Interfaces
Supports 2K/3G/HD/SD-SDI input, 2K/3G/HD/SD-SDI loop output, HDMI input (with lock), HDMI to SDI output (share SDI loop port), micro-USB (firmware upgrade), 3.5mm analog audio output.
Built-in HDMI to SDI Conversion
Supports built-in HDMI to SDI conversion; share the SDI loop output port. It's the same format conversion and supports the following HDMI formats: 480i, 576i, 720p (60/59.94/50), 1080i (60/59.94/50), 1080p (30/29.97/25/24/23.98).
Note:
When both SDI and HDMI are connected, if the current display source is SDI, the SDI output port is SDI loop; and if the current display source is HDMI, the SDI output port is HDMI conversion output.
Video Analysis Assistant Pattern
The supported video analysis assistant patterns include: Waveform (Y/Pb/Pr/R/G/B), Vectorscope, and Histogram (R/G/B/Y), to convert the digital video quality info (Luma, Color, Saturation, etc.) to patterns, and the patterns can be switched on/off individually.
Embedded audio monitoring
Supports SDI 16 channels and HDMI 8 channels embedded audio meters display, with marks and audio abnormal alert info. Users can also select any 2 channels audio to output via 3.5mm socket or speakers.
One-Key Menu and Function Keys
The monitor has a Revolve/Push Menu button, with one-button operation for menu system.
USB Firmware Upgrade
The monitor provides a micro-USB port for firmware upgrade. You can download the latest firmware file to a USB stick, and insert it into the S-1053F monitor (via micro-USB OTG cable) to upgrade, without PC connection.
Foldable Sunhood
For outdoor use, the S-1053F provides a foldable sunhood that snaps to the monitor.
Additional Features
- 5.5" LCD, 1920 x 1080 full HD
- Optical bonding LCD panel
- Metal housing, thinner, and robust
- Peaking focus assist (dual color)
- Timecode, H/V delay, AFD, and scale markers
- F1-F3 functions: Input source switch, max backlight, waveform, info display, color temperature, timecode, zebra, vector, audio meters, histogram, false color, AFD, H/V delay, R/G/B/Mono, scale markers, color bar, audio alert, peaking focus assist, aspect ratio, scan mode, zoom mode, mute, freeze frame, flip
- Lockable HDMI connector
Battery Plate
- Compatible with Canon BP-945/BP-970G battery and SWIT S-8845/S-8945 battery
- Structure and power pins ensure a stable and reliable connection
- 5.5mm DC plug for monitor
Write Your Own Review
Items Included:
- SWIT S-1053F 5.5" Full HD Waveform LCD Monitor with S-7003C Canon BP Battery Plate
- S-7003C Canon BP Battery Plate
- Foldable Sunhood
- D-Tap to Lockable Pole DC Cable
- AC-DC Lockable Power Adapter
- Cold Shoe / Screw Articulating Arm Trestle
- Lockable HDMI Cable (80cm)
- Flannelette Bag for Monitor
- Carrying Case
- Limited 1-Year Warranty for Battery Plate
- Limited 2-Year Warranty for Monitor
|
