| VIDEO OUTPUTS |
| Digital: | HD / SD-SDI up to 3Gb/s /1080p60
(SMPTE 259, 292, 424,425-A)
HDMI 1.3
Secondary SD-SDI (SMPTE 259) for simultaneous HD & SD playback |
| Analog: | YPbPr, RGB up to 1080p30, Composite, S-video |
| VIDEO INPUTS |
| Digital : | HD / SD-SDI up to 3Gb/s for seamless live video stream into a MPEG playlist |
| SUPPORTED FORMATS |
| Video Formats: | 1080p, 1080i, 720p, NTSC, PAL |
| Picture Size: | HD / SD |
| Chroma Sampling Format: | 4:2:2 & 4:2:0 |
| Profile: | HEVC up to Main422 10@ L4.1 High Tier |
| Color Standards: | BT.709 & BT.601 |
| File Formats: | MP4, MOV, MXF (OP1a/OP-Atom)
MPEG-2 PS / TS |
| Audio Codecs: | MPEG, LPCM, AAC, SMPTE302M, AC3 and SMPTE337M pass-through |
| Maximum Video Bit Rate: | Up to 20 Mbps (HEVC)
Up to 100 Mbps (H.264)
Up to 150 Mbps (MPEG-2) |
| AUDIO OUTPUTS |
| Embedded Audio Channe: | SDI (16), HDMI (8) |
| Digital: | AES3 (8) |
| Analog: | Unbalanced (2) |
| ADVANCED FEATURES |
| Seamless frame accurate playback: | Yes |
| RS-422 control: | Sony 9-pin protocol, device mode |
| VITC / LTC Output: | Yes |
| Closed captionning: | CEA608/708,608 Waveform |
| CC Transports: | SMPTE RDD11 and OP47
Add SMPTE436M for MXF files
ANSI/SCTE 128, ATSC A/72 [CC & AFD in AVC/HEVC user data]
ATSC A/53d, ANSI/SCTE 21 [CC & AFD in MPEG2Video user data]
ANSI/SCTE 20 (DVS 157) [CC in MPEG2Video user data]
ETSI EN 301 775 [Teletext data in separate TS stream] |
| Genlock/Reference Input: | Yes |
| Video / Audio adjustments: | Yes (Analog & Digital) |
| Upscaling / Downscaling: | Any to Any resolution with auto adaptive color conversion |
| Deinterlacing: | Yes |
| Streaming Interface: | Yes (UDP TS / RTSP / RTP, Unicast / Multicast) |
| Monitoring / Preview: | Yes |
| On Screen Display (OSD): | Full screen - Alpha-blended |
| Multiboarding: | Yes |
| DEVELOPER RESOURCES |
| Operating Systems: | Windows 7 / XP / Server 2003-2008 (32/64 bit) |
| Software: | Powerful end user application provided |
| Development Kits: | Livewire SDK & Stradis SDK |
| SYSTEM CONFIGURATION |
| Minimum Configuration: | H.264/MPEG-2: Pentium Dual Core 2.5 GHz, 2GB RAM
HEVC: Pentium Quad Core 3.1 Ghz, 4GB RAM |
| PCI Compliance: | PCIe rev1.1 (4 lanes) |
| Dimensions of the board: | 167.7 x 111.2 mm (6.60” x 4.38”) |
| Power consumption: | 10.3 W |
