Reliable IP to SDI Conversion

The IPR-10G2-SDI Bridging HD SMPTE ST 2110 Video and Audio to 3G-SDI is designed to receive SMPTE ST 2110 IP streams and convert them into high-quality SDI output. It enables seamless integration of IP-based workflows into traditional SDI environments.

High Performance Video and Audio Output

Supporting HD formats up to 1080p60, the device ensures accurate video reproduction with synchronized audio. It extracts audio from the IP stream and embeds it into SDI while also providing simultaneous analog audio output.

Redundant and Stable Transmission

With dual 10 GigE SFP+ ports, the unit supports hitless switching using SMPTE ST 2022-7. This ensures uninterrupted performance, making it ideal for broadcast monitoring and critical distribution workflows.

Flexible Output and Synchronization

Dual mirrored 3G-SDI outputs allow simultaneous connection to multiple devices such as monitors and recording systems. The reference input ensures that output is locked to facility timing for precise synchronization.

Compact and Professional Design

Designed with a rugged, fanless enclosure, the IPR-10G2-SDI operates quietly and reliably. Its compact form factor allows easy installation in studios, racks, or field setups.
