Analog Connectivity for Eclipse Matrix Systems

The MVX-A16-HX is a versatile analog interface card designed for Clear-Com Eclipse HX matrix intercom systems. It provides 16 ports of balanced line-level audio connectivity, allowing the intercom matrix to integrate with a wide range of communication devices and professional audio systems.

Plug-and-Play Integration

The card offers simple plug-and-play integration with Clear-Com devices such as V-Series Iris keypanels, 2X10 touch panels, and LQ SIP interfaces. It also supports connection to Eclipse interface modules for extended system functionality.

Support for Third-Party Audio Systems

Using balanced line-level four-wire audio connections, the MVX-A16-HX allows integration with external broadcast equipment and third-party communication systems. This flexibility makes it suitable for studio environments, live production systems, and facility communication networks.

Intelligent System Linking

The card can also be used to create intelligent linking trunks between Eclipse frames. This enables large intercom systems to expand across multiple matrix frames while maintaining consistent communication routing.

Centralized Configuration with EHX

All configuration and monitoring of the MVX-A16-HX card is handled through the EHX configuration software. This allows system administrators to manage audio routing, device connectivity, and port configuration across the entire Eclipse intercom infrastructure.
