Compact and Portable Signal Processing

The Evertz 350FR Portable Multiframe brings enterprise-grade video, audio, and fiber optic signal processing into a rugged, transportable 3RU package. Engineered specifically for field operations, outside broadcast (OB) trucks, flypack systems, and remote venue coverage, the 350FR accommodates up to seven single-slot Evertz 7700 series processing cards—delivering high-density processing without the footprint of a full-sized rack frame.

Complete 7700 Series Compatibility and Reliability

The 350FR is fully backward compatible with the complete lineup of Evertz 77xx series cards, supporting high-speed signal formats across both coaxial and optical domains (including 3G/HD/SD-SDI, analog video, digital audio, and CWDM/DWDM transport). Designed with zero-downtime maintenance in mind, the frame features a front-loading architecture where processing modules, cooling fans, and power supplies can be serviced or hot-swapped on the fly without removing rear cable connections or interrupting adjacent active paths.

Advanced Remote Control and Field Accessories

For mission-critical monitoring in remote production environments, slot 1 of the 350FR can be fitted with an Evertz 7700FC Frame Controller. This adds comprehensive network monitoring and SNMP configuration over IP using Evertz VistaLINK software. The frame can be deployed as a standalone desktop unit or mounted side-by-side using an optional dual-unit rack tray, while optional rain covers safeguard equipment during harsh outdoor events.
