Evertz 500DA-AESB | Balanced AES Audio 1x4 Reclocking Distribution Amplifier

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

1x4 Balanced AES Distribution: Distributes one transformer-coupled 110Ω AES3 input to four reclocked 110Ω balanced outputs.
Adaptive Equalization & Reclocking: Compensates for up to 300m (984ft) of Belden 1800B cable at 48kHz while reducing signal jitter.
Multi-Rate Sampling Support: Supports 32kHz, 44.1kHz, 48kHz, and 96kHz digital audio sampling rates.
Transformer-Coupled Isolation: Provides input isolation to prevent ground loops and maintain signal integrity.
Removable Terminal Connections: Uses 3-pin removable terminal strips with included screw-down adapter modules.
Comprehensive Monitoring & SNMP: Card-edge LEDs indicate module health, reclocker lock, PLL status, parity errors, and biphase coding errors, with remote SNMP monitoring via the 500FC Frame Controller.

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

Professional Balanced AES Digital Audio Distribution

The Evertz 500DA-AESB is a broadcast-grade 1x4 reclocking and auto-equalizing distribution amplifier designed specifically for balanced $110\ \Omega$ AES3 digital audio signals. Built for master control rooms, recording suites, and live broadcast infrastructure, it accepts a single balanced AES3 digital stream and delivers 4 pristine, jitter-reduced outputs across long cable runs.

Long-Distance Cable Equalization & Jitter Reduction

Automatic Long-Run Equalization: Integrated adaptive equalization compensates for cable attenuation up to $300\text{ m}$ over standard Belden 1800B twisted-pair cabling.
Active Data Reclocking: Restores digital pulse shapes and eliminates accumulated timing jitter before routing to downstream audio processors, routers, or consoles.
High-Resolution Sampling: Supports digital audio streams with sampling rates up to $96\text{ kHz}$, making it ideal for standard broadcast and high-sample-rate production workflows.

High-Density Modular Chassis Architecture

Designed to fit the 3RU Evertz 500FR frame, up to 16 500DA-AESB cards can be installed per chassis to support up to 64 balanced AES outputs. Quick-check card-edge LEDs provide instant status updates for fast diagnostic checks, while SNMP support allows centralized management across large facility networks.

Technical Specifications +

technical specifications
