Evertz 500DA-AESU | Unbalanced AES Audio 1x9 Reclocking Distribution Amplifier

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

1x9 Unbalanced AES Distribution: Distributes one transformer-coupled 75Ω AES3 input to nine reclocked 75Ω BNC coaxial outputs.
Extreme Cable Equalization: Compensates for cable losses up to 1500m (4920ft) over Belden 1694A at 48kHz.
Jitter-Reducing Reclocking: Restores digital waveform integrity and reduces timing jitter at 32kHz, 44.1kHz, 48kHz, and 96kHz.
SMPTE ST 276 Compliance: Supports AES3 digital audio transmission over standard 75Ω coaxial infrastructure.
Transformer-Coupled Isolation: Prevents ground loops and provides electrical isolation on single-ended coaxial connections.
Real-Time Diagnostics & SNMP: Card-edge LEDs monitor module health, reclocker lock, PLL status, parity, and biphase errors, with SNMP support via the 500FC Frame Controller.

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

High-Density Unbalanced AES Digital Audio Distribution

The Evertz 500DA-AESU is a broadcast-grade 1x9 reclocking and auto-equalizing distribution amplifier engineered for $75\ \Omega$ unbalanced AES3 digital audio signals (SMPTE ST 276). Designed for master control, production trucks, and large broadcast facilities, it splits a single coaxial AES stream into 9 clean, jitter-free outputs without signal degradation.

Long-Distance Cable Compensation & Clock Restoration

Extended Coaxial Reach: The onboard equalization engine automatically recovers degraded $75\ \Omega$ AES digital signals across coaxial runs up to $1500\text{ m}$ using Belden 1694A cable.
Jitter Reduction: Restores pulse integrity and eliminates phase jitter prior to distribution, ensuring maximum stability for downstream audio routers, consoles, and embedders.
Broad Sample Rate Support: Native compatibility with standard digital sampling rates from $32\text{ kHz}$ to high-resolution $96\text{ kHz}$.

Modular Integration & System Monitoring

Occupying a single slot in the 3RU Evertz 500FR frame, up to 16 cards can be populated per chassis for up to 144 distributed coaxial AES outputs. Card-edge LEDs provide instant status updates, while centralized management is enabled via SNMP when paired with the 500FC Frame Controller.

Technical Specifications +

technical specifications
