Precision Synchronization for Next-Generation Hybrid Broadcast Plants

The Evertz 5700MSC-IP is an enterprise-class IP network root leader clock, video sync pulse generator, and timecode reference system engineered for modern SMPTE ST 2110 IP-based broadcast and live production facilities. Designed to bridge the gap between traditional baseband SDI and high-speed IP networks, the unit provides rock-solid synchronization across both domains simultaneously. Equipped with a high-stability Oven Controlled Crystal Oscillator (OCXO) and a multi-constellation GNSS receiver system, it guarantees ultra-precise frequency and time lock across demanding studio, OB truck, and transmission environments.

Unmatched IP Network Timing Flexibility and Resilience

Built for mission-critical infrastructure, the 5700MSC-IP features four dedicated, independently configurable IP timing interfaces—two 10GbE SFP ports and two 1GbE RJ-45 ports. This quad-interface design allows network engineers to build fault-tolerant, meshed PTP timing architectures capable of recovering from network link failures without degrading the root leader hierarchy. The unit natively supports PTP profiles including SMPTE ST 2059-2, AES67, and IEEE 1588 Annex J, alongside NTP and PCR, making it a comprehensive timing core for broadcast and production workflows.

Flexible Baseband Sync and Custom Test Pattern Options

In addition to its IP capability, the 5700MSC-IP includes six independently timeable HD-BNC analog reference outputs to feed existing baseband equipment with Black Burst, HD Tri-Level sync, 10MHz references, and Word Clock signals. For expanded test pattern generation, optional upgrade packages allow the system to output SD/HD/3G-SDI baseband video (+SDITG) or ST 2110-20/30 IP video and audio streams with ST 2022-7 redundancy (+10GTG), both capable of combining channels to form 4K UHD test patterns in 2sI or Square Division formats.

Comprehensive Remote Management and Hardware Options

Designed for seamless integration into enterprise management frameworks, the 5700MSC-IP provides full in-band and out-of-band management via standard web browser interfaces, Telnet, and SNMP monitoring. The 1RU chassis includes a 50ft cable and smart antenna for immediate outdoor GNSS deployment, with long-distance fiber extension options available. Power redundancy is easily achieved via an optional second power supply, ensuring continuous operation and high system availability in round-the-clock broadcasting facilities.
