Evertz

Evertz 5782DEC-H264HD-IPASI Professional H.264 & MPEG-2 Decoder Platform

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

Multi-Format Decoding: Supports H.264/AVC, MPEG-2 up to 4:2:2 10-bit Hi422P@4.1, and optional JPEG2000 up to 300Mbps.
Dual ASI & IP Ingest: Provides 2x ASI BNC inputs and 2x GbE ports supporting UDP/RTP, SPTS/MPTS, optional ST 2022-1 FEC, and ST 2022-7 hitless redundancy.
ANC Data Reconstruction: Preserves VANC/HANC metadata including captions, Teletext, Timecode, AFD/WSS, and optional SCTE 35-to-104 translation.
Multi-Channel Audio: Supports up to 8 audio PIDs and 16 embedded PCM channels with MPEG-1 Layer 2, Dolby AC-3, PCM/Dolby pass-through, optional Dolby-E, and AAC-LC.
HD-to-SD Down-Conversion: Optional HDC converts HD-SDI to SD-SDI with fixed scaling or AFD-based aspect ratio control.
Modular Single-Slot Design: Compatible with Evertz 7700, 7800, and 570 series frames with optional frame sync reference.
VistaLINK SNMP Management: Enables centralized configuration, service selection, and network monitoring via VistaLINK Pro.

Pricing Dhs. 0.00

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

Professional Baseband & IP Decoding Infrastructure

The Evertz 5782DEC-H264HD-IPASI is a high-density, professional decoding card engineered for broadcast monitoring, contribution decoding, and baseband downstream processing. Designed to occupy a single slot in Evertz 570, 7700, and 7800 series frames, this versatile platform processes incoming transport streams delivered via dual Gigabit IP Ethernet or DVB-ASI connections.

Pristine Video Decompression & Metadata Integrity

Handling high-bitrate feeds up to 80 Mb/s for H.264/MPEG-2 (and up to 300 Mb/s for optional JPEG2000), the 5782DEC-H264HD-IPASI delivers pristine video feeds up to 1080p59.94. It preserves complete broadcast compliance by extracting and reconstructing all VANC/HANC metadata—including timecode, closed captions, and active format descriptors—directly into its dual 3G/HD/SD-SDI baseband outputs.

Field-Upgradable & Network-Ready Architecture

Built for evolving broadcast environments, the module supports field-upgradable licensing for advanced 4:2:2 10-bit decoding, Dolby-E processing, and frame synchronization. With dual IP data ports supporting hitless redundancy (SMPTE ST 2022-7) and full integration into the Evertz VistaLINK® ecosystem, the 5782DEC-H264HD-IPASI ensures reliable operation for critical live broadcast workflows.

Technical Specifications +

technical specifications
