Evertz 7700ADA-AUD | Dual Balanced Analog Audio Distribution Amplifier

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

Flexible Channel Operation: Configurable as dual-channel 2x1x4 stereo DAs or a single-channel 1x8 mono DA.
Universal Input Compatibility: Accepts balanced differential or single-ended analog audio with automatic single-ended-to-differential conversion.
Multi-Stage Gain Control: Provides 0/+6.5dB input gain, 0/3.5/9.5dB output gain, and continuous -6.5dB to +9.5dB fine gain adjustment.
Broadcast-Grade Audio Fidelity: Delivers up to 119dB SNR, 0.001% THD+N, and ±0.02dB frequency response from 20Hz to 20kHz.
Superior Noise Rejection & Isolation: Provides >115dB CMRR at 60Hz and >110dB inter-channel isolation.
High Output Drive Capability: Supports up to +28dBu into high-impedance loads and +24dBm into 600Ω loads.
Modular Frame Compatibility: Occupies one slot in Evertz 7700FR, 7800FR, or 570-series modular frames.

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

High-Performance Analog Audio Splitting & Distribution

The Evertz 7700ADA-AUD is a general-purpose, dual-channel analog audio distribution amplifier designed for professional broadcast facilities, recording suites, and master control environments. Built for high-density signal distribution, it delivers clean, uncolored analog audio signals across multiple destinations without loading effects or crosstalk.

Flexible Stereo/Mono Configuration & Fine Gain Staging

Dual Operational Modes: Operate as two independent 1x4 amplifiers for stereo left/right pairs, or combine channels into a single 1x8 amplifier when high-fanout mono distribution is required.
Multi-Stage Level Tuning: Jumper coarse gain stages combined with card-edge trim potentiometers allow precise gain matching across various pro-audio line levels.
Ultra-Low Noise Architecture: Extended dynamic range ($119\text{ dB}$ SNR) and exceptional headroom (up to $+34\text{ dBu}$ max input level) preserve signal integrity in critical production signal chains.

Modular Frame Integration

Designed to occupy a single slot in the Evertz 7700FR, 7800FR, and 570 series 3RU frame chassis, multiple cards can be installed per frame to build high-density distribution systems. Card-edge LEDs provide instant visual indication of module power and fault status.

Technical Specifications +

technical specifications
