Advanced Stereoscopic 3D Processing and Alignment

The Evertz 7832SVP-3G and 7832SVP-444-3G are second-generation stereoscopic video processor modules engineered specifically for 3D live production, post-production, and broadcast transmission. Occupying two slots in 7800 series frames, the module processes synchronized Left Eye and Right Eye program feeds while providing comprehensive 2D monitoring tools for convergence pulling, camera alignment, and color matching. Integrated Camera Flip modes compensate for beam-splitter camera rigs by swapping eyes or mirroring images horizontally and vertically without requiring external conversion hardware.

Comprehensive 3D Formatting and Dual-Engine Mixing

Equipped with versatile auxiliary output routing, the 7832SVP series drives 3D-capable display panels and frame-compatible playout systems in Top-and-Bottom, Side-by-Side, and Line Interleave formats. Built-in mixer engines generate real-time visual diagnostics—including 50/50 blend, difference, luma-only difference, horizontal split, tile, anaglyph, and wiggle modes—to ensure precise physical and optical camera alignment. Horizontal Image Translation (HIT) allows engineers to adjust the stereoscopic convergence plane on auxiliary monitoring outputs without modifying active program signal paths.

High-End 4:4:4 Cinematography and Temporal Correction

The upgraded 7832SVP-444-3G model expands processing capabilities to support 12-bit 4:2:2 and 10-bit 4:4:4 RGB video formats up to 2K digital cinematography resolutions ($2048 \times 1080$). It features user-programmable 2D Look-Up Tables (LUTs) to linearize logarithmic cinema camera signals for accurate monitoring, along with dual-link ST 372 to ST 425-1 conversion. When equipped with the optional +STM module, the unit utilizes IntelliTrak™ technology to automatically analyze and re-time temporal offsets up to $\pm$10 frames between eye channels, solving synchronization issues across separate backhaul links.
