Multi-Format Frame Synchronization & Signal Protection

The Evertz 7847FSE series provides broadcast-grade frame synchronization and signal conditioning for 3G-SDI, HD-SDI, and SD-SDI infrastructure. Occupying a single slot in Evertz 7800FR (3RU), 7801FR (1RU), and 7700FR-C frames, the module re-times incoming asynchronous video feeds against local black burst or HD tri-level reference signals. To maintain uninterrupted signal flow in mission-critical broadcast chains, the card features dual inputs (A & B) with Smart 2x1 protection switching and a mechanical bypass relay on the primary output to pass clean video even if power is lost.

Full Video Proc Amp & VANC Metadata Preservation

Equipped with an integrated video processing amplifier, the 7847FSE allows operators to fine-tune black level, luminance gain, and chrominance gain. The unit fully preserves all VANC metadata—including timecode, closed captioning, and custom ancillary data—while repeating or dropping frames as necessary to maintain genlock. AFD insertion can be triggered seamlessly via GPI or SNMP commands. On signal loss, the card can be set to freeze the last valid frame, output black, or bypass directly.

Advanced 16-Channel Audio Engine & Remote Control

The module processes 16 channels (4 groups) of embedded audio, allowing independent video and audio delay compensation. Its standard audio processing suite supports total channel remapping, gain adjustments, phase inversion, and stereo-to-mono mixing. Optional software licenses expand capabilities to include stereo-to-5.1 upmixing, downmixing, and automated loudness management to smooth out commercial volume variations. Centralized monitoring and control are provided via VistaLINK® SNMP or dedicated VUE hardware control panels when integrated with a 7800FC Frame Controller.
