Evertz MIO-TM2-4K Dual Path 12G/3G/HD Timecode Processor | SCORPION Module | ATC/VITC/LTC Generator & Inserter

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

Dual 12G-SDI Paths: Processes two independent 12G/3G/HD-SDI channels for single-link 4K/UHD workflows.
Hybrid Timecode Handling: Reads, generates, monitors, and inserts LTC, ATC-VITC, and ATC-LTC from SDI and SMPTE ST 2110-40 sources.
Flexible I/O: Provides 4 HD-BNC inputs, 4 HD-BNC outputs, and 2 internal SCORPION crosspoint inputs/outputs.
Advanced OSD: Displays timecode and user bits with 3 font sizes and adjustable background mask opacity.
Timecode Transcoding: Converts between ATC-VITC, ATC-LTC, LTC, and reference VITC formats.
Phase Diagnostics: Measures and monitors timecode phase differences across both processing paths.
SCORPION Integration: Compact dual-slot MIO module supports all Evertz SCORPION frames with SNMP and web management.

Pricing Dhs. 0.00

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

Next-Generation 12G-SDI & IP Timecode Processing

The Evertz MIO-TM2-4K is a dual-channel 12G/3G/HD-SDI timecode processing module engineered for the Evertz SCORPION ultra-compact frame ecosystem. Designed to meet the demands of modern 4K/UHD live production and IP hybrid infrastructures, the MIO-TM2-4K combines timecode reading, generation, translation, and character insertion into a high-density, dual-slot MIO form factor. It offers full support for SMPTE ST 2110-40 ancillary data streams as well as traditional SDI baseband signals.

Complete Signal Matrix and Chassis Crosspoint Integration

Each independent video processing path features three input channels (2x external HD-BNC main/backup inputs and 1x internal chassis crosspoint input) and three output channels (1x HD-BNC Monitor output, 1x HD-BNC Program output, and 1x internal chassis crosspoint output). This comprehensive routing architecture allows seamless distribution of clean program video, monitored video with timecode burn-in, or internal frame routing without extra external cabling.

Advanced Visual Character Burn-In and Transcoding

Equipped with a high-resolution On-Screen Display (OSD) engine, the module can burn generator/reader timecode and user bits directly into the picture on both MON and PGM outputs. Operators can customize window positioning, select from three font sizes, and adjust background mask opacity. The module natively transcodes between ATC-VITC, ATC-LTC, and reference VITC while providing real-time timecode difference diagnostics between both processing channels.

Seamless Control and Compact Modular Deployment

Occupying just two slots in any SCORPION frame (such as SCORPION-2F, SCORPION-6F, or SCORPION-S18/SX18), the MIO-TM2-4K delivers enterprise-grade performance with an operating temperature rating up to 85°C. System configuration, status monitoring, and remote management are handled easily through Evertz WebEasy, SNMP control, or RESTful APIs.

Technical Specifications +

technical specifications
