Evertz MViP-II-DPX4 High-Density IP Multi-Image Display & Monitoring Solution

Name: Evertz MViP-II-DPX4 High-Density IP Multi-Image Display & Monitoring Solution
Brand: Evertz

Evertz Signal Processing

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

High-Density IP Decoding: Decodes up to 128 SD/64 HD MPEG-2/H.264, 64 SD/32 HD/8 4K HEVC, or 16 JPEG 2000 streams.
Broad Stream Support: Ingests UDP, RTP, SRT, RIST, HLS, MPEG-DASH, RTMP, LSS, HDS, MMSH, MMST, and HTTP/HTTPS.
Quad DisplayPort Outputs: Provides 4x DisplayPort 1.4A mosaic outputs from XGA to 4K UHD, with DP-to-HDMI adapters.
High-Bandwidth Connectivity: Includes 2x 10GbE SFP data ports and 4x 1GbE RJ-45 ports for management and data.
Signal Quality Monitoring: Supports TR 101 290 Priority 1/2 analysis plus video freeze, black, macroblocking, audio levels, loudness, and SCTE-35 monitoring.
Subtitle & Metadata Decoding: Supports up to 9 DVB subtitles/captions per program, plus CEA-608/708, Teletext, and XDS.
Redundant 2RU Hardware: Linux-based 2RU chassis with hot-swappable dual 850W/1200W redundant power supplies.
Unified Monitoring & Control: WebRTC UI integrates with VistaLINK and MAGNUM-NMS for routing, fault logging, and round-robin monitoring.

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

Next-Generation High-Density IP Multiviewer

The Evertz MViP-II-DPX4 is an enterprise-grade multi-image display and signal monitoring engine designed for digital headends, IPTV operators, OTT distribution hubs, and broadcast facilities. Expanding the renowned MViP-II family into 10GbE IP infrastructures, this 2RU platform processes a versatile mix of video formats—from legacy MPEG-2 to high-efficiency HEVC and uncompressed JPEG 2000—delivering real-time multi-screen monitoring across up to four 4K UHD screens.

Comprehensive IP Transport & Codec Compatibility

Engineered to handle diverse transmission workflows, the MViP-II-DPX4 supports all major streaming protocols used across contribution, distribution, and OTT delivery. Whether ingesting reliable transport protocols like SRT and RIST, compressed unicast/multicast streams (MPTS/SPTS), or adaptive bit-rate OTT streams (HLS, MPEG-DASH), the system ensures seamless decoding and signal verification across all inputs. Optional RF and ASI input expansion is also available via Evertz 7780DM and 7880IP series modules.

Automated Signal Fault Auditing & Enterprise Management

Beyond multi-image tile rendering, the MViP-II-DPX4 acts as an automated 24/7 signal analyzer. It continuously evaluates video integrity (black screen, frozen frame, macroblocking), audio parameters (loudness, over/under levels, Dolby E decoding), and transport stream health (TR 101 290 P1/P2, bandwidth high/low, SCTE-35 triggers). Managed via a modern WebRTC interface or integrated directly into Evertz MAGNUM-NMS, the processor enables dynamic "Penalty Box" workflows to immediately flag compromised streams for operators.

Technical Specifications +
