FOR-A FA-1010 10-Channel Multi-Purpose Signal Processor

FOR-A Processors

Professional broadcast product designed for reliable production, streaming, and modern media workflows.

Genuine
Product

Official
Warranty

Technical
Support

Fast
Delivery

Key Features

10 Processing Channels: Includes frame synchronizers and color correctors.
10×10 Clean Switch: Provides glitch-free Direct, Take, and Salvo switching.
3G/HD/SD-SDI: Supports Level-A/B signals with cross-conversion.
4K QFHD Mode: Combines channels for dual 4K processing.
Advanced Audio: Supports up to 160 embedded channels with remapping.
Flexible Sync: Offers Frame, Line, and AVDL synchronization modes.
Reliable Control: Includes relay bypass, optional redundant power, and web control.

Pricing Dhs. 0.00

Request a Quote

Secure checkout. Authorized partner. 100% genuine products.

Details that matter

Features & Specifications

Explore the features, technical details, and everything you need to know about this product.

Need help choosing? Talk to our experts →

Product Overview +

Compact 10-Channel Broadcast Engine

The FOR-A FA-1010 is a multi-channel signal processor that packages ten frame synchronizers and ten color correctors into a space-saving 1U rackmount chassis. Purpose-built for high-density environments like network operation centers, sub-control rooms, mobile OB trucks, and live event production, the FA-1010 processes up to 10 independent 3G/HD/SD-SDI video feeds simultaneously. Internal routing circuits allow multi-channel processing without messy external cabling, while an integrated 10x10 clean switcher enables seamless video and audio switching.

Advanced Color Correction & 4K Capabilities

Each of the ten processing channels includes a Proc Amp and a dedicated color corrector featuring Balance (RGB), Differential, and Sepia modes, complemented by Y/Pb/Pr and RGB clipping functions to keep signal levels within broadast standards. By enabling its 4K link mode, the unit pairs multiple internal channels to operate as two complete 4K (QFHD) square-division processors. Inter-convertible 3G-SDI Level-A and Level-B support resolves signal compatibility issues across mixed-gear infrastructure.

High-Density Audio Remapping & Modular I/O Options

The base unit manages 16 channels of embedded audio per SDI line (up to 160 channels across all 10 inputs) with full channel remapping, gain control, 1-ms step delay (up to 1,000 ms), down-mixing, phase polarity reversal, and sample rate conversion. Optional audio cards expand capacity up to 192 channels:

Digital Audio: FA-10AES-BL (8-channel balanced AES/EBU) and FA-10AES-UBL / FA-10AES-UBLC (unbalanced AES/EBU).
Analog Audio: FA-10ANA-AUD (4-channel balanced/unbalanced analog audio with built-in mic head amplifiers and phantom power).
Control & Redundancy Options: FA-10GPI expansion card, FA-10RU remote control panel, FA-10DCCRU color control panel, FA-AUX30 extension panel, and FA-10PS redundant power supply.
