Compact & Scalable 4K/HD Monitoring Hub

The FOR-A MV-3240 is a high-density, 1RU multiformat multi viewer designed for live broadcast production, studio master control, OB trucks, and digital signage monitoring. Supporting up to 32 video inputs across 3G/HD/SD-SDI and optional 12G/6G-SDI formats, the unit provides clean up/down-resizing between 4K UHD and HD resolutions. To accommodate larger monitoring installations, up to four MV-3240 frames can be cascaded together, significantly expanding total input density while maintaining ultra-low processing latency.

Versatile Multi-Window Layouts & Audio Processing

Using intuitive Windows-based Layout Manager software, operators can customize screen layouts with up to 25 windows on a single 4K display or up to 40 windows distributed across four 2K screens. Configurations can be stored directly on the frame and recalled instantly from the front panel. On-screen monitoring capabilities include multi-channel embedded audio level meters, tally indicators, custom graphic logos, timecode, and scheduled timers. Audio monitoring is supported via SDI embedded output and HDMI embedded audio.

Remote M-JPEG Streaming & Advanced Fault Detection

Beyond local baseband outputs, the MV-3240 includes an integrated M-JPEG streaming engine for remote web browser monitoring and LiveViewer software integration. Built-in error detection constantly tracks frozen video frames and signal anomalies, triggering visual flashing borders, error icons, and SNMP traps. The system also supports pre-alarm recording, automatically saving error footage to a networked PC drive for immediate review and troubleshooting.
