Enterprise-Grade Multi-Screen Visual Monitoring

The FOR-A MV-4000 Series represents a versatile generation of high-density multi viewers built for large-scale broadcast facilities, master control rooms, flypacks, and mobile OB units. Available in compact 2RU (MV-4200 series) and modular 3RU (MV-4300 series) frames, the system supports up to 68 video inputs and can drive up to 8 independent displays with 114 customized video windows. The architecture seamlessly ingests mixed baseband feeds—including single-link 12G-SDI, 3G/HD/SD-SDI, DVI-I, HDMI, RGBHV, and analog composite signals—ensuring complete signal distribution flexibility.

Flexible Chassis Lineup & Modular I/O Cards

The series includes dedicated hardware configurations engineered for specific output workflows. The standard MV-4200 and MV-4300 models feature 4 SDI and 4 HDMI outputs, while the SDI-only MV-4210 and MV-4310 provide 8 3G-SDI outputs. For native 4K UHD processing, the flagship MV-4220 and MV-4320 models incorporate standard 12G-SDI I/O with support for single-link 12G and Quad Link (2SI/SQD) 3G-SDI. Input capacity can be expanded using optional MV-4200SDI, MV-4220SDI, MV-4200PCI graphics cards, and MV-4200IF interface boards for GPIO, genlock, serial control, and analog/AES audio integration.

Advanced HDR Workflows & On-Screen Layout Management

Equipped with dynamic HDR/SDR conversion, the MV-4000 series allows operators to monitor Hybrid Log-Gamma (HLG) HDR and standard SDR content side-by-side without color distortion or blown-out brightness. The system automatically matches multi-viewer graphic overlays—such as tallies, audio level meters, titles, and clocks—to the target display's dynamic range. Using the intuitive Windows-based Layout Manager software, users can save up to 68 custom layout patterns directly to the frame and recall them instantly via network or front panel controls.
