Professional 4K Capture Performance

The Magewell Pro Capture AIO 4K Plus is designed for high-performance video capture, supporting resolutions up to 4096 × 2160. It enables smooth and reliable capture of both HDMI and SDI sources with embedded audio for professional workflows.

Flexible Dual Input Support

This capture card features HDMI and SDI inputs, allowing seamless integration with a wide range of cameras, switchers, and broadcast equipment. It supports automatic or manual input source selection for efficient operation.

Advanced Video Processing Capabilities

Equipped with powerful processing pipelines, the card supports deinterlacing, scaling, cropping, color conversion, and aspect ratio adjustments. It ensures optimized video output tailored to various production needs.

Ultra-Low Latency & High Efficiency

With ultra-low latency as low as 64 video lines, this card is ideal for live streaming and real-time applications. Its efficient SG-DMA architecture ensures high data throughput with minimal system load.

Multiple Streams & Multi-Card Support

The card supports unlimited capture streams per channel and allows multiple cards to be installed in one system. Each stream can be configured independently for resolution, frame rate, and color settings.

Wide Compatibility & SDK Integration

Compatible with major operating systems and APIs such as DirectShow, DirectKS, and V4L2, the card integrates easily into existing workflows. It works with popular streaming and production software like OBS, VLC, and Wirecast.
