Dual-Channel 4K SDI Capture Performance

The Magewell Pro Capture Dual SDI 4K Plus Capture Card is engineered for high-end broadcast and production environments, enabling simultaneous capture of two independent SDI signals in resolutions up to DCI 4K.

Flexible Multi-Link SDI Support

Designed for modern workflows, it supports single-link 12G-SDI, dual-link 6G-SDI, and quad-link 3G-SDI configurations, ensuring compatibility with a wide range of professional cameras and switchers.

Advanced Video Processing Engine

Equipped with powerful onboard processing, the card delivers real-time cropping, scaling, deinterlacing, frame-rate conversion, and color adjustments while maintaining high image quality.

Ultra-Low Latency & Real-Time Sync

With latency as low as 64 video lines and hardware-based timestamping, it ensures precise audio-video synchronization, making it ideal for live production and streaming.

Scalable Multi-Card Deployment

Multiple cards can be installed in a single system, each configurable via an onboard rotary switch, allowing scalable multi-channel capture setups.

Professional Reliability & Continuous Operation

Built for demanding environments, the card supports 24/7 continuous operation, high-speed memory processing, and stable data transfer via SG-DMA technology.
