Versatile Multi-Format Video Capture

The Magewell Pro Capture DVI HD Capture Card supports a wide range of input formats, including DVI, HDMI, VGA, and Component. This flexibility makes it ideal for capturing video from legacy and modern devices in professional environments.

High-Quality Video Performance

With support for resolutions up to 2048 × 2048 and frame rates up to 120 fps, the card ensures smooth and high-quality video capture. It also supports multiple color formats and up to 10-bit processing for enhanced image fidelity.

Advanced Video Processing Engine

The card features powerful onboard processing capabilities including scaling, cropping, de-interlacing, aspect ratio conversion, and frame rate conversion. These tools allow users to optimize video output for various applications.

Flexible Audio Capture & Synchronization

Capture embedded HDMI audio (up to 8 channels) or analog audio via the 3.5mm input. Advanced timestamping and AV synchronization ensure accurate audio-video alignment.

Multi-Stream & Multi-Card Capability

Supports unlimited output streams per input channel, each with independent settings. Multiple cards can be installed in one system, making it highly scalable for professional workflows.

Ultra-Low Latency & Reliable Operation

Designed for real-time applications, the card offers ultra-low latency performance and stable data transfer through PCIe, ensuring minimal delay in live production environments.
