Overview

The Neutrik NAC3MPX-TOP is a powerCON TRUE1 TOP male chassis connector designed for professional AC power distribution in demanding indoor and outdoor environments. Configured as a Power OUT appliance outlet, it features 1/4-inch flat tab terminals and a secure locking interface for reliable power connections in broadcast, entertainment, and industrial applications.

Professional Power Performance

Rated for 16 A at 250 V AC (20 A UL), the NAC3MPX-TOP features Circuit Breaking Capability (CBC), allowing safe connection and disconnection under load. When used with the optional SCNAC-MPX sealing cover, it provides IP65 and UL50E Type 4 protection in the mated condition or with the protective cap closed, making it suitable for outdoor installations and harsh environments.

Durable Professional Construction

Built for long-term reliability, the connector features a UV-resistant high-impact housing, silver-plated contacts, stainless steel locking components, and a durable twist-lock mechanism rated for thousands of mating cycles. Its D-size chassis design enables straightforward integration into professional equipment and power distribution panels.

Applications

•
  Professional stage lighting

•
  Broadcast equipment

•
  Live sound systems

•
  Outdoor AV installations

•
  Touring and rental systems

•
  Power distribution panels
