Neutrik NK-NBNC75BJP9 rearTWIST HD BNC Connector | 75 Ohm Crimp | Broadcast HD Video

HD BNC for Broadcast Video

The Neutrik NK-NBNC75BJP9 is a rearTWIST HD BNC cable connector for broadcast and professional video. The listing describes a true 75 ohm design suited to HD applications. It is a crimp connector, so it is fitted to the cable with a matched tool rather than soldered, which keeps assembly quick on large jobs. Confirm the required length and connector type when you request a quote.

The rearTWIST Boot and Colour Coding

The connector uses a patented rearTWIST boot that gives easy access in high-density racks and patchbays. The boot also offers colour coding, which helps technicians identify circuits and reduce wiring mistakes when many BNCs sit close together on a panel. Check the specification against your project brief before placing an order. Confirm the required length and connector type when you request a quote.

Crimp Dimensions and Compatible Cables

The pin is 1.6 mm square and the shield crimp is 6.47 mm hex. The listing names suitable cables including Belden 1505F, Bryant BD SD53F, Cordial CVI 08-37 HD, Klotz VD083LP and Tesca Presto. Always check the crimp size against the specific cable before fitting. Share the route and quantity with your enquiry so the quote matches the job.

Fitting and Testing

Strip the cable to the connector's dimensions, fit the pin and crimp the shield with the correct tool. Test the finished termination with an SDI or HD analyser, since a loose shield or poor crimp is the most common source of return loss problems in HD video links. Confirm the required length and connector type when you request a quote.

Choosing This BNC
