Overview

The Neutrik NRJ4HH-1 is a 1/4 inch TS mono switched audio jack designed for horizontal PCB mounting in high-density panel layouts. Featuring a half-threaded nose and sleeve contact/front panel connection, it is suitable for professional audio equipment requiring compact PCB spacing and dependable switching performance.

Professional Switching Audio Performance

Designed for professional audio signal routing, the NRJ4HH-1 incorporates two switching contacts and a retention spring that maintains secure plug engagement. The compact design allows installation on 15.88 mm center spacing, making it ideal for densely populated PCB assemblies and patching systems.

High-Density PCB Mount Construction

The jack features a durable polyamide housing with silver-plated bronze contacts for reliable signal transfer and long service life. Its horizontal PCB mount configuration supports efficient equipment design while maintaining robust mechanical performance through more than 10,000 mating cycles.

Applications

•
  Professional audio equipment

•
  Audio mixers and processors

•
  Signal routing and patching systems

•
  Studio and recording equipment

•
  AV integration systems

•
  High-density PCB audio assemblies
