Hybrid Fibre and Power Cable

The Percon 0539 is a hybrid cable designed for mobile applications where digital signals travel over multimode fibre and power is supplied remotely. It is typically used for camera systems where the camera head needs both a high-bandwidth video link and a single-phase supply at a distance from the power source. Confirm the required length and connector type when you request a quote.

Fibre and Power Conductors

The cable has two multimode optical fibres and two power conductors within one jacket. The listing shows the power section is rated for a maximum of 600 volts single-phase, which is the limit to design the power distribution around. Keeping the fibres and power cores together simplifies rigging and reduces the number of cables on a camera position.

Anti-Rodent Shield and Jacket

A braided fibreglass overall shield gives anti-rodent protection, and a very flexible polyurethane jacket covers the cable. The nominal diameter is 10.5 mm and the cable is listed for mobile installation, so it suits outdoor camera positions and temporary rigs where rodents or rough handling may be a concern. Check the specification against your project brief before placing an order.

Termination and Testing

Multimode fibre terminations must be cleaned and inspected before mating, because dust on the end face is a common cause of link loss. Power conductors need correct termination to the local electrical standard, and the fibre link should be tested with a light source and power meter before the camera system is put into operation.

Choosing the Hybrid Cable

Choose the 0539 hybrid for remote camera runs that need fibre and power in one cable. For a fibre-only link, the FO450DDOM3PUR/XTREM is the multimode option. Quotes are issued by length and termination type, so state the power requirement and the fibre length when you enquire. Share the route and quantity with your enquiry so the quote matches the job.
