RB-PMX4 10-Input, 4-Output Analogue Preset Mixer | Secure Routing Matrix
Product
Warranty
Support
Delivery
Key Features
Key Features
- 10×4 Configurable Audio Matrix Mixer
- Flexible Input-to-Output Routing
- Independent Input Gain Controls
- Individually Buffered Outputs
- Balanced XLR Professional Connectivity
Features & Specifications
Product Overview +
The "Set-and-Forget" Solution
The RB-PMX4 is engineered for the professional audio infrastructure where constant adjustment is unnecessary. Whether acting as a four-bus mini-mixer, a localized zone mixer for hospitality venues, or a multi-channel clean-feed generator, it provides a stable and reliable signal processing platform that is securely configured upon installation.
Engineered for Flexibility and Performance
Despite its fixed configuration, the RB-PMX4 offers immense routing flexibility. Its ability to normalize varying consumer and professional signal levels makes it highly versatile for system integrators. With an ultra-low distortion profile (<0.01%) and a flat frequency response (20Hz–20kHz), it maintains the high-fidelity standard required for professional broadcast and sound reinforcement environments.
Reliable Infrastructure Asset
As part of the Sonifex Redbox series, the RB-PMX4 is built for years of continuous, failure-free operation. Its compact 1U rack-mount design and individually buffered outputs ensure that it remains a stable, essential workhorse for broadcast facilities and installation sites across Pakistan, Africa, and the UAE, where technical consistency is of paramount importance.
Technical Specifications +
technical specifications
