Elite 4K60 Imaging Mastery

The Bolin R9-420N Indoor 4K60 FreeD NDI PTZ Camera stands at the pinnacle of remote production technology, purposed for premium broadcast studios, corporate AV, live sports analytics, and next-generation virtual environments. At its core lies the high-performance 1/2.8-type Sony IMX715 image sensor matched to a bespoke 8MP ultra-high-resolution lens assembly. This pairing outputs vibrant, noise-free, native 3840x2160 video at 60fps, utilizing a deep 120dB Super WDR profile to protect fine highlights and shadow gradients across erratic stage or stadium lighting configurations.

Unified Architecture and NDI Embedded Bridge

Built to pioneer decentralized AV-over-IP workflows, the R9-420N comes NDI 6 ready, supporting Certified Full NDI High Bandwidth and low-bandwidth NDI HX3 streams directly out of the box. It features an onboard NDI Embedded Bridge engine, which fundamentally changes global multi-site production by allowing the camera to transmit securely encrypted NDI streams across wide-area networks (WAN) without complex IT setups. This allows broadcast engineers to control, monitor, and mix high-quality feeds from multiple worldwide locations over standard internet lines with plug-and-play ease.

Immersive AR/VR Tracking and Precision Mechanics

For augmented and virtual reality stages, the R9-420N integrates native FreeD (Free Dimensional) tracking data telemetry. The camera continuously outputs three-dimensional axis data mapping its 255-step robotic mechanical movements to connected graphic rendering engines. This guarantees that sweeping pan, tilt, and zoom movements correspond with virtual digital backdrops with zero displacement. To maintain absolute structural stability, internal image stabilization isolates micro-vibrations, while an integrated carrying handle prevents drops during fast physical field installations.

Uncompromising Broadcast Connectivity

The rear interface of the R9-420N delivers simultaneous True Dual-Output versatility to accommodate traditional baseband and networked environments alike. Production teams can leverage dual 12G-SDI ports, a native HDMI 2.0 output, and an SFP Optical SDI module slot for long-range, secure fiber-optic transmission lines. Multi-camera setups utilize hardware Genlock synchronization for exact frame-level switching, while professional audio routing is managed cleanly via a balanced dual-channel XLR audio input/output block that ties in through a secure 10-pin LEMO connector.
