Extreme Low-Light Mastery

The Bolin R9-230H FHD Low-Light Performance PTZ camera sets a new standard for challenging production environments. Powered by an elite 1/1.8-type Sony STARVIS II sensor and an advanced ISP engine, this robotic camera achieves high visibility where traditional cameras fail. It isolates color detail and suppresses digital noise under low-ambient or erratic stage lighting, making it an essential asset for music venues, broadcast studios, auditoriums, and high-motion dark environments like nightclubs.

Long-Range Precision and Vibration Defying Stability

Equipped with an 8M high-resolution 30x optical zoom lens, the R9-230H bridges the gap between wide panoramic establishing shots and tight, detail-rich closeups. Operating over long throw distances introduces the risk of structural camera shake, which this model systematically neutralizes using its onboard Super Image Stabilization Plus technology. This physical correction layer dampens micro-movements caused by bass heavy subwoofers, heavy crowds, or truss flex, securing clean video frame stability.

Flexible Unified Broadcast Workflows

Designed to harmonize traditional baseband video with modern network distribution, the camera features a professional backpanel supporting simultaneous signal delivery. Production teams can extract true dual-output configurations via dual 3G-SDI, HDMI 1.4, and a built-in SFP optical module slot designed for long-distance secure fiber runs. Hardware Genlock synchronization ensures exact frame alignment across multiple cameras, while dual-channel balanced XLR audio flows directly through a secure 10-pin LEMO breakout connection.

Immersive VR and AR Positioning Telemetry

Beyond standard streaming, the R9-230H features native FreeD protocol integration to satisfy advanced visual tracking demands. The camera constantly logs its internal 255-step precise robotic mechanical movements—calculating real-time pan, tilt, zoom, and orientation metadata—and passes it to connected AR/VR graphics processors. This enables production teams to execute sweeping camera shifts that link perfectly with virtual background engines, simplifying immersive storytelling workflows.
