Low-Light Mastery with STARVIS 2 Core

The Bolin R9-230NX NDI HX3 PTZ Camera sets a premium standard for imaging performance in low-ambient and highly erratic lighting environments. Integrating a state-of-the-art 1/1.8-type Sony STARVIS 2 image sensor with an 8MP ultra-high-resolution optical block and advanced ISP processing, this camera achieves unparalleled color visibility where standard tracking systems fade to noise. It isolates clean, faithful resolution details in near-dark settings, making it an indispensable asset for live music venues, theaters, dark houses of worship, and high-energy sports broadcasting.

Vibration-Defying Optics and Fluid Stability

Outfitted with an extensive 30x enhanced optical zoom lens, the R9-230NX captures wide establishing room tracking and crisp, remote close-ups with absolute confidence. To mitigate physical camera shake when operating at maximum focal magnification, the camera incorporates Super Image Stabilization Plus technology. This physical hardware stabilization layer counteracts structural micro-movements caused by heavy audio subwoofers, stage bass, or truss flex, securing a perfectly smooth and reliable video frame throughout high-motion productions.

Global WAN Networking via NDI Embedded Bridge

Engineered to streamline modern decentralized broadcast workflows, the R9-230NX comes completely NDI 6 ready with integrated NDI HX3 support. It features an onboard NDI Embedded Bridge engine that completely redefines remote multi-site contribution by allowing encrypted audio, video, and control data to pass directly over wide-area networks (WAN). This design cuts through complex IT firewalls and router configurations, providing field operators with a plug-and-play user experience to monitor, mix, and control globally distributed live feeds with minimal latency.

True Multi-Output Flexibility and Virtual Studio Integration

The rear architecture of the R9-230NX delivers simultaneous True Dual-Output connectivity to bridge legacy baseband workflows with advanced IP infrastructures. Video switchers can independently draw from dual 3G-SDI ports, a native HDMI interface, and a high-speed SFP Optical SDI module slot designed for long-distance fiber line runs. For advanced immersive productions, integrated FreeD protocol support feeds instant 3D axis metadata to virtual AR/VR graphics processors. Set synchronization is managed accurately via hardware Genlock, while professional sound boards connect through balanced XLR breakout leads and an on-set 3.5mm intercom line.
