Advanced 12-Channel Full HD Production

The Datavideo SE-3200 is a top-of-the-line, professional 1080p video switcher designed for large-scale live event production. It features a versatile 12-input architecture (8x SDI and 4x HDMI) and 9 outputs, providing the connectivity needed for sophisticated broadcast environments. Every input is equipped with a built-in scaler, allowing for automatic up and down conversion to ensure that every source—whether from a professional camera or a laptop—integrates seamlessly into your Full HD workflow.

FlexSource: The Power of 2 M/E in a 1 M/E Switcher

The SE-3200 introduces FlexSource, a powerful engine that provides nearly the composition power of a 2 M/E switcher within a 1 M/E unit. This allows you to create complex, multi-layered image compositions featuring up to four PiP windows with 3D borders, a background layer, and an additional key layer. These sophisticated setups can be saved as presets and recalled instantly, making it an ideal choice for high-pressure broadcast studios and outdoor broadcast (OB) vans.

Professional Virtual Studio & Visual Effects

Enhance your production value with a comprehensive suite of visual tools. The SE-3200 supports 4 channels of switchable chromakey with Datavideo's unique "Key Tie" functionality, enabling a complete 4-channel virtual studio experience. Additionally, the switcher supports Stinger transitions, animated logos, and a 2D DVE. With 50 pre-saved virtual set backgrounds and the included CG-200 title creator software, you can deliver broadcast-quality graphics directly from a standard laptop via HDMI.

Rugged Rackmount Design & Dual Multiview

Engineered for easy installation, the SE-3200’s main unit is mountable in any standard 19-inch rack, while the ergonomic control panel is designed for flat-surface operation. It supports Dual Multiview outputs, allowing you to connect two separate displays to monitor your sources. With fully customizable multiview layouts and Crosspoint assignment (XPT), operators can reroute physical inputs and outputs to any button on the fly, ensuring a highly efficient and personalized mixing experience
