All-in-One Live Production Solution

The Datavideo SE-650 is a compact and cost-effective solution that combines a four-channel HD video switcher with a professional six-channel audio mixer. This integrated design makes it the perfect choice for small-scale live productions, houses of worship, and corporate studios. By supporting both HD-SDI and HDMI inputs, the SE-650 allows you to mix professional broadcast cameras with HDMI sources like laptops or consumer camcorders, providing a high-quality broadcast output without the need for additional equipment.

Professional Effects and Visual Layering

Elevate your broadcast with advanced visual tools usually found in larger consoles. The SE-650 features a flexible mix-effects processor with an upstream keyer for chroma, linear, and luma keying, plus a dedicated Picture-in-Picture (PiP) engine. With 32 built-in wipe patterns—complete with border and softness controls—and professional logo insertion, you can deliver a polished, TV-style production. The built-in XPT (Cross Point Assignment) and tally output ensure that your production workflow remains efficient and organized.

Versatile Audio Mixing and Output Routing

Sound is just as important as video, and the SE-650 handles it brilliantly. The integrated 6-channel audio mixer supports embedded audio from your video inputs as well as analog audio via 1/4" microphone and RCA inputs. The output section is fully configurable; you can independently assign outputs for Program (with DSK), Clean Program, or Multiview. This flexibility allows you to send one feed to a streaming encoder for live broadcast while simultaneously sending a clean feed to a dedicated recorder.

Built for Reliability and Speed

Designed for fast-paced live environments, every input on the SE-650 features a built-in frame synchronizer. This ensures seamless, glitch-free switching even when using cameras that are not genlocked. The tactile control surface provides immediate access to angles, fades, and transitions, allowing the operator to focus on the creativity of the show. Whether you are broadcasting a live podcast in the UAE or a school event in Pakistan, the SE-650 offers the reliability and ease of use required for professional results every time.
