Powerful V6MU Engine & 6 M/E Performance

The FOR-A HVS-2000 HANABI is a game-changing 2M/E production switcher engineered to power high-demand live broadcast, stage monitoring, and multi-room control environments. Utilizing FOR-A’s V6MU engine, the HVS-2000 combines two full M/E buses with four independent MELite™ buses. This unique architecture gives operators the functional performance of a 6 M/E switcher, allowing full previews, mixes, cuts, and keying across multiple stage monitors, secondary web feeds, or auxiliary outputs from a single chassis.

Flexible Multi-Layer Keying & Advanced DVEs

Equipped with four dedicated keyers per M/E and four system-wide FLEXaKEY™ channels, the switcher allows up to eight keyers to be combined on a single M/E for complex picture-in-picture graphics. Built-in DVE processing includes four 2.5D DVEs per M/E with flying key functionality, as well as four 3D DVEs offering dynamic page turn and surface warping effects. These capabilities allow operators to effortlessly composite virtual studios, sports broadcast titles, and multi-screen visual layers.

Scalable Baseband I/O & Ergonomic Control

The HVS-2000 features 24 inputs and 18 outputs in its standard configuration, with six expansion slots enabling field upgrades up to 48 inputs or 22 outputs. It handles standard 3G-SDI and HD-SDI baseband formats alongside PC graphics inputs and optional legacy analog feeds. On-set operation is managed through an ergonomic hardware panel equipped with color-coded button illumination, individual button macro displays, a 7-inch mini-menu touch screen, and a 3-axis XYZ joystick.
